Product Details:
|
Product Name: | Anti Climb Fence | Color: | Black |
---|---|---|---|
Frame Material: | Metal | Metal Type: | Low Carbon Steel Wire, Galvanized Wire |
Panel Height: | 1.8m, 2.1m, 2.4m, 3m | Panel Width: | 2.2m, 2.4m, 3m |
Hole Size: | 12.7x76.2mm;12.5x75mm | Wire Thickness: | 4.0mm |
Post Length: | 2700mm, 3000mm, 3600mm | Post Size: | 60x60mm, 60x80mm, 80x80mm |
Highlight: | Black Color 358 Anti Climb Fence,358 Anti Climb Fence For Prisons,4.0mm Anti Climb Fence Panels |
Anti Climb Fence |
||||||||||
Mesh |
Wire Thickness |
Surface Treatment |
Folds Nos |
Panel Width |
Height |
|||||
76.2×12.7mm |
Horizontal wire:3,3.5,4mm Vertical wire: 4mm |
Galvanized and Electrostatic polyester powder coated or hot dipped galvanized
|
3 |
2.5m or 2.2m |
1800mm |
|||||
3 |
2000mm |
|||||||||
4 |
2100mm |
|||||||||
4 |
2200mm |
|||||||||
4 |
2400mm |
|||||||||
5 |
2500mm |
|||||||||
6 |
3000mm |
|||||||||
Weld strength:-75% of the minimum tensile strength of the wire;Tensile range 540-690 N/m² |
||||||||||
Panel-Type C(2D View,adding wire) |
||||||||||
Mesh |
Wire Thickness |
Surface Treatment |
Panel Width |
Height |
||||||
100×15mm |
Horizontal wire:3.5mm Vertical wire: 5.5mm |
Galvanized and Electrostatic polyester powder coated or hot dipped galvanized
|
2.5m or 2.2m |
1800mm |
||||||
2000mm |
||||||||||
2100mm |
||||||||||
2200mm |
||||||||||
2400mm |
||||||||||
2500mm |
||||||||||
3000mm |
||||||||||
With additional horizontal wire of 3.5mm at 18cm intervals |
||||||||||
Weld strength:-75% of the minimum tensile strength of the wire;Tensile range 540-690 N/m² |
