Green Powder Coated Anti Climb Mesh Fence High Security 358 Anti Cut Prison Mesh For Industrial

Certification
China Anping Yuanfengrun Mesh Products Co., Ltd. certification
I'm Online Chat Now

Green Powder Coated Anti Climb Mesh Fence High Security 358 Anti Cut Prison Mesh For Industrial

Green Powder Coated Anti Climb Mesh Fence High Security 358 Anti Cut Prison Mesh For Industrial
Green Powder Coated Anti Climb Mesh Fence High Security 358 Anti Cut Prison Mesh For Industrial
Green Powder Coated Anti Climb Mesh Fence High Security 358 Anti Cut Prison Mesh For Industrial Green Powder Coated Anti Climb Mesh Fence High Security 358 Anti Cut Prison Mesh For Industrial Green Powder Coated Anti Climb Mesh Fence High Security 358 Anti Cut Prison Mesh For Industrial

Large Image :  Green Powder Coated Anti Climb Mesh Fence High Security 358 Anti Cut Prison Mesh For Industrial

Product Details:
Place of Origin: Hebei P.R. China.
Brand Name: X MESH
Certification: ISO9001:2015
Model Number: X MESH-anti climb mesh fence088
Payment & Shipping Terms:
Minimum Order Quantity: 100m2
Price: USD 0.5-5.0/square meter
Packaging Details: Pallet or Wooden Case packing
Delivery Time: 5-8 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000 pcs per Week

Green Powder Coated Anti Climb Mesh Fence High Security 358 Anti Cut Prison Mesh For Industrial

Description
Product Name: Anti Climb Mesh Fence Color: Green, Blue, Black,white,yellow, Red
Mesh Size: 12.7x76.2mm, 12.5x75mm Or Customized Horizontal Wire: 3mm-5mm,etc
Vertical Wire: 3mm-5mm,etc Height: 1.8m, 2.1m, 2.4m, 3m Or Customized
Length: 2.2m, 2.4m, 3m Or Customized Square Post(SHS): 2700mm, 3000mm, 3600mm Or Customized
Post Size: 60x60mm, 60x80mm, 80x80mm Or Customized Surface Treatment: Galvanized Electrostatic Spraying
Highlight:

High Security Anti Climb Mesh Fence

,

358 Anti Climb Mesh Fence

,

Green Powder Coated 358 mesh fencing

Green Powder Coated Anti Climb Mesh Fence High Security 358 Anti Cut Prison Mesh for Industrial



Anti Climb Mesh Fence Introduction:

The 358 anti-climbing fence, also known as "358 mesh fence," is a high-security fencing system that consists of closely spaced horizontal and vertical wires, typically with a mesh size of 76.2mm x 12.7mm. The main advantages of the 358 anti-climbing fence include its high level of security due to the small mesh size, making it difficult to climb or cut through. It also provides good visibility and is difficult to penetrate or vandalize.

Product name

Anti Climb Mesh Fence

Color

Green, blue, black,white,yellow, red

Mesh Size

12.7x76.2mm, 12.5x75mm or customized

Horizontal wire

3mm-5mm,etc

Vertical wire

3mm-5mm,etc

Height

1.8m, 2.1m, 2.4m, 3m or customized

Length

2.2m, 2.4m, 3m or customized

Square post(SHS)

2700mm, 3000mm, 3600mm or customized

Post Size

60x60mm, 60x80mm, 80x80mm or customized

Surface Treatment

galvanized Electrostatic spraying



Anti Climb Mesh Fence Specification:

- 358 Security Fence also called high security fence, anti-climb fence, prison fence.It is extremely difficult to penetrate and difficult to attack using conventional hand tools. It has the features of anti-climbing and anti-cutting.

- 358 Security Fence is wide used for Retail,industrial and commercial properties, schools, public utilities, airports, secure
units.



ANTI CLIMB FENCE

Panel height

2100mm

2400mm

3000mm

Fence height

2134mm

2438mm

2997mm

Panel width

2515mm

2515mm

2515mm

Hole size

12.7mm×76.2mm

12.7mm×76.2mm

12.7mm×76.2mm

Horizontal wire

4mm

4mm

4mm

Vertical wire

4mm

4mm

4mm

Panel weight

50kg

57kg

70kg

Post

60×60×2mm

60×60×2mm

80×80×3mm

Post length

2.8m

3.1m

3.1m

Clamp bar

40×6m slotted

40×6m slotted

40×6m slotted

Fixings

8 gal bolt c/w permanent security nut

No. of fixings

8

9

11

Customization accepted







C post

62mm×83mm×3mm

round post

outside diameter:80mm×3mm

rectangular post

60mm×80mm×3mm,60mm×120mm×3mm

post length

on request (normal 2.3mm-4m)

material

square steel pipe , round steel pipe , C type steel

finished

hot dipped galvanized,pvc coated

polyester painting color

Any RAL color (dark green, black,ect.)

Mesh Opening

Wire Thickness

Panel Width

Height









76.2×12.7mm





Horizontal wire:

3.0 ,3.5 ,4.0mm



Vertical wire:

4.0mm









2.50m / 2.20m

1800mm

2000mm

2100mm

2100mm

2400mm

2500mm

3000mm

FENCE HEIGHT

MESH SIZE(H×W)

MESH WEIGHT(kg)

1.27m

1270 × 2515 mm

29.1 kg

2.4m

2400 × 2515mm

55.5 kg

2.7m

2700 × 2515 mm

62.5 kg

3.0m

3000 × 2515 mm

62.5 kg

3.3m

3300 × 2515 mm

76.4 kg

3.6m

3600 × 2515 mm

83.4 kg

4.0m

4000 × 2515 mm

92.6 kg

4.5m

4500 × 2515 mm

104.2 kg

4.8m

4800 × 2515 mm

111.1 kg

5.2m

5200 × 2515 mm

120.4 kg



Anti Climb Mesh Fence Feature:

Anti-climb and anti-cut, more security;

Corrosion is resistant to zinc aluminium alloy and PVC powder coating;

Multi height standard options;

Support V-Bends, more strength and rigidity;

Use square pole, maximum security and strength



Anti Climb Mesh Fence Packaging and shipping:

<1>Plastic film at the bottom to avoid the panel be destroyed

<2>4 metal corners to ensure the panel strong and uniform

<3>wood plate at the top of pallet to keep the under panel

<4>pallet tube size:40*80mm tubes at the botom vertical position

Post & Accessories packaging

Post:

<1>The caps have been installed on the top of post, which reduce your labor cost and installing time

<2> Each post are packed by a long plastic bag avoiding damaged by friction

<3>All posts are packed by metal pallet for loading and unloading

Accessories: Clips and screws are packed by sets, plastic film + carton box. Carton Box Dimensions: 300*300*400m



Anti Climb Mesh Fence Application:

1.Bridge anti-climb guarding&guard safety screening;
2.Sub-station security fencing;
3.Psychiatric hospital security fencing;
4.Factory machine guards;
5.Walkway security fencing;
6.Airport security fencing;
7.358 wire mesh fenc gates;
8.Shipping port security fencing;
9.Electrical sub-station fencing;
10.Water treatment works;



Anti Climb Mesh Fence  FAQ:



1.Q: Are the welding points easily to get broken?

A: Please do not worry about it. We will test the tensile strength during the production.

2.Q: Are the fences get rust easily?

A: Before painting,the fences must be sand-blasted and cleaned three times: water cleaning-- parkerising-- water cleaning.

The powder we use are Dupont or Aksu which are the international famous brands,to ensure the plastic layer beautiful ,

firm and smooth, the surface is resistant to ultraviolet and corrosion.

3.Q:If the quality is not met my request, how do you solve this problem?

First of all, we don’t allow any defective products to leave our factory.We do strict quality inspection in every step and guarantee to

reduce the defective rate to less than 0.1%. But if there is any problem, we will guarantee to solve it within 2 working days after

your pictures or videos proof.

4.Q. What is your sample policy?

A: We can supply the sample if we have ready parts in stock, but the customers have to pay the courier cost. And all the sample

cost will be refunded after you place the order.

5.Q: How long warranty does your company can provided for fence product?

A: Our product can last for 10 years at least. Usually we will provide 5-10 years guarantee.

6.Q: Can I be your agent?

We warmly welcome all kinds of cooperation, Please emails us for more details.

7.Q: How is your after sale?

After the goods are sent, we will track them in real time and give you timely feedback. After you receive the goods, we will have a

dedicated staff to return visits, if there is a problem, we will reply to you within 2 working days

8.Q: Can you design and make as customers' request?

A: Yes, we will do as the detailed specification from the customers,and professional recommendation will be offered to customers.
